TLR 22X AC 1/10 2wd Race Buggy Kit, Astro/Carpet
SKU: TLR-1234
Loading...
TLR takes the lessons of its revolutionary 22 series and launches the next era of electric racing dominance with the 22X AC 2WD kit — a brand new design with more adjustability for higher speed capabilities on today’s high-grip astro and carpet surfaces.
- Includes sway bars
- Large volume gear diff is new
- Increased steering response from narrow king pin and larger scrub offset spindle and carrier
- For more stability on astro and carpet tracks the chassis is +3 longer
- For more consistency proper stiffness composites are included
- For higher grip surfaces where needed a steel electronics tray provides weight
- 2mm machined 7075-T6 hard-anodized aluminium chassis
- New gearbox in laydown format with easy-access idler gear and differential
- Big bore shocks are larger 13mm type for optimal cornering and handling
- Bigger 13mm shock springs for increased support
- -5 degree to 5 degree caster adjustability in 2.5 degree increments
- Kick up can be adjusted from 20 degrees to 25 degrees in 2.5 degree increments
- Multiple offsets available on steering settings to get the feel you need for the racing surface
- Front wheels offset to industry standard
- 4mm woven rigid carbon fibre shock towers on front and rear
- Consistent feel on all track features provided by refined steering geometry
- 5.8mm balls on new ball studs and rod ends for interference-free movement
- Pro-line Sector 22X lightweight body
- 7” Air Force low-mount front wing and clear rear buggy wing
- Customise tuning rigidity with fibreglass-filled composite parts in multiple stiffnesses
- Advanced rear grip tuning possible with multiple rear arm lengths available
- Race tested Variable Height Axle (VHA) rear hubs with easy roll and bite adjustment
- Refine rear toe and anti-squat with adjustable rear pivots
- New layout on the Super Heavy Duty Slipper (SHDS) for enhanced vehicle balance
- Motor fan mount built in for 30mm x 30mm fans
- Right out of the box, you get maximum tunability – no extra parts needed
- Location of shock towers has been optimised
- Covers on shock towers to prevent rollovers causing track damage
- Battery mount is adjustable
- Many lightweight aluminium parts – axles, pivots, chassis, ball stud washers, motor plate, 25T clamping servo horn, A/B front outer camber black, shock stand offs, rear clamping hexes
